Economy Lock Hidden Shackle Padlock
- Description
- Applications & Compatibility
- Features & Usage
- Specifications
-
Economy Lock Hidden Shackle Padlock
The Economy Lock Hidden Shackle Padlock is a compact commercial-grade padlock designed to provide added protection for trailers, trucks, gates, storage areas, equipment, and other applications where a concealed shackle is beneficial.
Its hidden-shackle design places the shackle inside the lock body, helping reduce access for common prying and cutting attempts. The reinforced die-cast body provides a durable housing for demanding commercial and industrial applications.
The lock features a 3/8" boron alloy shackle and a rekeyable 6-pin cylinder. With its compact round-body design and concealed shackle, it is particularly well suited for applications where a conventional exposed-shackle padlock may be more vulnerable to tampering.
This hidden-shackle design is commonly used for transportation, industrial, storage, and equipment-security applications where protecting the locking point is important.
-
Applications & Compatibility
The Hidden Shackle Padlock is designed for commercial, industrial, transportation, and general security applications where the locking point can accommodate a hidden-shackle padlock.
Common Applications:
- ✓ Truck and trailer security
- ✓ Trailer doors and locking points
- ✓ Security gates and fences
- ✓ Storage units and lockers
- ✓ Sheds, workshops, and garages
- ✓ Tool boxes and job boxes
- ✓ Commercial and industrial equipment
- ✓ Transportation and fleet applications
Compatible Locking Hardware:
The lock is designed to work with compatible hasps and locking points that provide sufficient clearance for its concealed shackle and body.
Important: Verify the dimensions of the existing hasp or locking point before purchase. The hidden-shackle configuration requires compatible mounting hardware with appropriate clearance.
-
Key Features
- ✓ Hidden-shackle design
- ✓ 2-7/8" wide reinforced die-cast body
- ✓ 3/8" diameter boron alloy shackle
- ✓ Rekeyable 6-pin cylinder
- ✓ Keyed-different configuration
- ✓ Concealed shackle helps reduce access for prying and cutting
- ✓ Compact round-body design
- ✓ Designed for commercial and industrial applications
- ✓ Suitable for transportation and equipment security
Hidden Shackle Design
Unlike a conventional padlock with an exposed U-shaped shackle, the shackle on this lock is recessed inside the body. This design helps shield the shackle from direct access and makes the lock particularly useful for protected locking points.
Keyed Different
This configuration is keyed different, meaning each individual lock is supplied with its own key combination. The rekeyable cylinder also provides flexibility for compatible keying requirements.
Note: If multiple locks need to operate with the same key, verify that a keyed-alike version is available before ordering.
-
Product Specifications
- Brand: Master Lock
- Model: 6271
- Product Type: Hidden Shackle Padlock
- Lock Type: Keyed Padlock
- Body Material: Reinforced zinc die-cast
- Body Width: 2-7/8" (73 mm)
- Body Shape: Round
- Shackle Type: Hidden Shackle
- Shackle Material: Boron Alloy
- Shackle Diameter: 3/8" (10 mm)
- Shackle Length: 19/32" (15 mm)
- Shackle Width: 1-23/32" (44 mm)
- Cylinder: 6-Pin W7000
- Rekeyable: Yes
- Keying: Keyed Different
- Color: Silver
- Application: Commercial, industrial, transportation, and equipment security
Important: The padlock is intended for security applications and should be used with a compatible, properly installed hasp or locking point. Always verify the required dimensions and application before installation.
